I love pipes. Anytime I can pipe something somewhere, it seems that order has claimed a victory over chaos. In fact, there is pipe-related photo of me at the end of this article for your viewing pleasure.

The other day I was working in NodeJS and wanted to pipe a readable stream to a spawned child process.

I wanted something that could do this.

const process = createProcess(args);
const zq = createTransformStream(process);
const data = input.pipe(zq); // <-- Very cool

await client.load(data);

The child process needed to be a wrapped in a transform stream that would feed data to stdin and pass on data from stdout.

Spawn a Child Process

First, I spawned my process. NodeJS provides the spawn function to fire up an executable on your file system. The return value is a ChildProcess object.

function createProcess(args) {
  // Massage your args for the binary you're using.
  return spawn(bin, spawnargs);
}

Wrap the Child Process in a Transform Stream

Now we need to wrap that process in a transform stream so that we can pipe, pipe, pipe.

The steps:

1. Receive a chunk of data as an argument in the transform function.
2. Write that chunk to the child’s stdin .
3. Receive data coming from the child’s stdout .
4. Push that data into the transform stream.
5. Handle errors and clean up.

Here is the code.

function createTransformStream(child) {
  const stream = new Stream.Transform({
    transform(chunk, encoding, callback) {
      if (child.stdin.write(chunk, encoding)) {
        process.nextTick(callback);
      } else {
        child.stdin.once("drain", callback);
      }
    },

    flush(callback) {
      child.stdin.end();
      if (child.stdout.destroyed) callback();
      else child.stdout.on("close", () => callback());
    },
  });

  child.stdin.on("error", (e) => {
    if (e.code === "EPIPE") {
      // finished before reading the file finished (i.e. head)
      stream.emit("end");
    } else {
      stream.destroy(e);
    }
  });

  child.stdout
    .on("data", (data) => stream.push(data))
    .on("error", (e) => stream.destroy(e));

  child.stderr
    .on("data", (data) => stream.destroy(new Error(data.toString())))
    .on("error", (e) => stream.destroy(e));

  return stream;
}

Before we go into detail about what this code does, let’s discuss a very confusing topic for me, NodeJS streams.

Understanding NodeJS Readables

A readable is like a file. Call readable.read() to get the first chunk of data from the file.

const chunk = readable.read();

But if I am creating my own readable, it starts off empty. There is no data to read. To add some, use the readable.push() method.

readable.push("my-chunk-of-data");

This was confusing to me, because I am essentially “writing” data into the readable. But don’t say it like that, because the write() method name is already taken as we’ll see next.

Understanding NodeJS Writables

A writable is a destination for data to land. The writable thing takes the data I give it with writable.write() and does something with it. To indicate that I have written all the data I have to it, I call writable.end().

writable.write("first chunk");
writable.write("second chunk");
writable.write("ok, i'm done");
writable.end();

Understanding NodeJS Duplex Streams

To make everything super confusing, some objects can be both readable and writable. This means I can call .push(), .read(), .write(), and .end() on these things.

A special type of duplex stream is called the transform stream. It provides a shorthand way of reading from a source and writing to a destination. That’s what I used in the code above.

Detailed Code Breakdown

First we create the transform stream which will be the return value. We implement two methods in the constructor, transform() and flush(). The first is called when a chunk of data is read from a source, the second is called when there’s no more data to read.

The Transform Function

transform(chunk, encoding, callback) {
  if (child.stdin.write(chunk, encoding)) {
		process.nextTick(callback);
  } else {
		child.stdin.once('drain', callback);
  }
}

The transform function has the arguments chunk, encoding, and callback. The chunk is the bit of data that was just read and the callback is supposed to be called after I’ve processed it.

I pass that bit of data to my child process by writing to the process stdin. If stdin.write() returns true, it’s ready to accept more data so I call the callback on the next tick. If it returns false, it wants me to wait for the "drain" event before continuing, so we call the callback once that event is fired. This is called “respecting back-pressure.” Respect.

The Flush Function

flush(callback) {
  child.stdin.end();
  if (child.stdout.destroyed) callback();
  else child.stdout.on('close', () => callback());
}

The flush function is called when the stream has finished reading the source. It has one callback argument that should be called when I’ve cleaned everything up. In the body, I tell the child process’ stdin that I will no longer write any more data. Then I wait for the child process’ stdout to close before calling the callback.

Listening to stdout

child.stdout
  .on("data", (data) => stream.push(data))
  .on("error", (e) => stream.destroy(e));

This is where I “push” the data that comes out of my child process into the transform stream. If there’s an error, I call destroy and pass in the error.

Listening to stderr

child.stderr
  .on("data", (data) => stream.destroy(new Error(data.toString())))
  .on("error", (e) => stream.destroy(e));

This is some error handling. In my case, if anything gets pushed into stderr, I consider it an error and destroy the transform stream providing the appropriate error text.

Listening to stdin

child.stdin.on("error", (e) => {
  if (e.code === "EPIPE") {
    // the process finished before reading the file finished
    stream.emit("end");
  } else {
    stream.destroy(e);
  }
});

More error handling. Sometimes the child process would finish before I had given it all of the file. (The case where I only want the first 5 lines of a long file.) I write to stdin, but it’s closed up and emits the error code "EPIPE". I handle that by emitting the "end" event on the transform stream. This was the only way I could get it to work. I tried calling .end() but that didn’t cut it. I had to emit the event manually.

If the error code is anything else, I destroy the stream like above.

article.end()

That’s is how I wrapped a NodeJS ChildProcess with a Stream.Transform object so that I can pipe data to and from it. I hope this saves you some time so that you can get back to your pipes.

Here’s me with my pipes in 2015.
